Factory Direct PTO Shaft for Tractors and Agricultural Implements

Replacement PTO shafts for PEECON vertical feed mixers 865, 1100, 1300 and 1500. CAT6 constant velocity main shaft; tractor-side spline options 1.375-6 (540 rpm), 1.375-21 (1000 rpm) and 1.750-20 (1000 rpm); mixer-side input typically 1.750-6. Automatic cutout clutch torque 2,500–3,500 N·m; shear bolt yokes rated 2,920 N·m. Shaft length, yoke size, spline combination and shield configuration can be made to drawing. MOQ and lead time are confirmed per order because they depend on the model and the configuration. Send your mixer model and tractor PTO spline — we confirm the driveline combination and issue a quotation.

Raydafon has been deeply involved in the field of agricultural machinery in China for more than ten years. The PTO Shaft for Supreme Feed Mixers developed by Raydafon to address the power transmission problems of feed mixers is an ideal partner for tractors with 60-180 horsepower. This drive shaft uses a φ55mm thickened hexagonal tube and a double-sealed cross universal joint, which can carry a torque of 3200Nm and a speed range of 540-1000rpm. In actual use, it can not only improve the uniformity of feed mixing by 25%, but also shorten the mixing time of a single batch by 12 minutes. As a factory direct supply source, Raydafon not only provides prices lower than imported brands, but also can provide non-standard customization according to customer needs. It is a high-quality supplier of cost-effective transmission components.
